JEF to EXP Converter: Free Online, No Sign-Up
JEF is the native format of Janome, Elna and Kenmore machines; EXP, a minimal format used by Bernina and Melco, carries no colors. Convert JEF to EXP for free, no sign-up: stitches, jumps and trims stay identical; the section order is kept so you can reassign threads on the machine.
Drop your .JEF file here
or click to browse your files
Convert to EXPYour files are only used to perform the conversion. Privacy policy
- No sign-up
- Instant design preview
- Files deleted immediately
- Processed on an EU server
How it works
1. Drop your file
Drag and drop your JEF file or select it from your computer.
2. The conversion starts
Your design is automatically converted to the EXP format, keeping all embroidery stitches.
3. Download the result
Instantly get your EXP file, ready to use on your embroidery machine.
Converter limits and specs
- Free conversions
- 2 free conversions every 24 h, no sign-up required.
- Maximum file size
- 10 MB
- Supported formats
- PES, DST, JEF, EXP, VP3 (input and output)
- Sign-up
- None for free use
- File storage
- None: deleted immediately after conversion
What changes in the JEF to EXP conversion
EXP receives your Janome design stitch sequence and nothing else: it is the leanest format in the matrix, ideal for Bernina and Melco machines.
- The color palette is lost: EXP carries no colors, only thread-change stops.
- No design name or dimensions: EXP is a pure stitch sequence.
- The color section order is preserved: follow it when assigning threads.
- Stitches, jumps and trims stay strictly identical.
JEF or EXP: what are the differences?
| JEF .jef | EXP .exp | |
|---|---|---|
| Typical use | Home embroidery | Home (Bernina) and industrial (Melco) |
| Machines concerned | Janome, Elna, Kenmore | Bernina, Melco |
| Colors | Color palette (Janome thread catalog) | No palette: thread-change stops only |
| Metadata | Design dimensions, color palette | No rich metadata (stitch sequence only) |
| How to open it | With Janome Digitizer or the free Wilcom TrueSizer | With the free Bernina ArtLink or Melco software |
Understanding the JEF and EXP formats
JEF .jef · as a source file
JEF sets out with the strengths of a Janome home format: stitches in tenths of a millimeter, explicit dimensions and a color palette backed by the Janome thread catalog. When the target format accepts a palette, your colors follow; otherwise, the section order remains the guide for reassigning threads.
- BrandsJanome, Elna, Kenmore
- HoopsFixed table: from 80 × 80 mm to 140 × 200 mm
- ColorsPalette (Janome thread catalog)
- MetadataDesign dimensions, selected hoop
- Internal unitTenth of a millimeter
EXP .exp · as an output file
As a target, EXP serves Bernina and Melco machines: a minimal file with no ambiguity about geometry. Since no metadata is embedded, dimensions are not stored and colors remain to be assigned on the machine, in the section order inherited from the source.
- BrandsBernina (home), Melco (industrial)
- HeaderNone: the file starts directly with the stitches
- ColorsNo palette: thread-change stops
- EncodingSame as DST (3 bytes), without a header
- MetadataNone (no name, no dimensions)
Machine compatibility and dimensions
JEF and EXP share the same base unit (the tenth of a millimeter): geometry passes to the millimeter. EXP does not keep dimensions in a header — the Bernina or Melco machine recomputes them from the stitches — so check the screen before starting, especially for large designs.
Other conversions from the JEF format
Frequently asked questions
How do I convert a JEF file to EXP?
Drop your .jef file in the conversion area above: the conversion to EXP is automatic. All that is left is to download the converted file.
EXP or DST for my Bernina machine: which one?
Both work: neither carries colors. If your Bernina natively accepts EXP, it is the most direct choice; DST remains useful as a universal copy reusable on any other machine.
How do I open a JEF or EXP file?
JEF files open with Janome Digitizer or the free Wilcom TrueSizer; EXP files open with the free Bernina ArtLink or Melco software. You can also convert JEF to EXP online for free with StitchConverter.
Is the JEF to EXP conversion free?
Yes. StitchConverter offers 2 free conversions every 24 h, with no sign-up. For unlimited use, go Premium (€1 per 24 h or €5 per month).
Do I need an account to convert a file?
No, no sign-up is required for free use. A Premium account is created automatically when you purchase, and you are identified by e-mail.
